Dimensions |
|
|
Length overall, m |
127 |
|
Length between perpendiculars, m |
121 |
|
Breadth overall, m |
34,7 |
|
Hull height up to the main deck, m |
7,5 |
|
Hull height up to the upper deck, m |
11,0 |
|
Overall height, m |
64 |
|
Draft fully laden, m |
5,56 |
|
Light draft counter balanced (free of provisions, free of ballast) (bow / stern) |
2,4 / 5,29 |
|
Displacement of vessel fully loaded with cargo, t |
21392 |
|
Displacement of the vessel unloaded, t |
12179 |
|
Deadweight, t |
9213 |
|
Net tonnage, t |
4001 |
|
Gross tonnage, t |
11264 |
|
Capacities |
|
|
Crew, person |
50 |
|
Installation staff, person |
70 |
|
Cargo deck, surface area, m2 |
952 |
|
Specific load on the deck, t/m2 |
10 |
|
Helicopter deck, diameter in meters |
23 |
|
Fuel reserves, m3 |
620 |
|
Lubricating oil, m3 |
27 |
|
Fresh water, m3 |
1200 |
|
Bilge water, m3 |
110 |
|
Endurance, days |
30 |
|
General Data |
|
|
IMO number |
7604374 |
|
Port of registry / Call sign |
Baku / 4JCJ |
|
Purpose Of The Ship |
Derrick Crane Barge |
|
Flag |
Azerbaijan |
|
Year built / builder |
1980 / "Bloom and Voss", Hamburg, Germany |
|
Class |
КМ ✪Л4 1 I |
|
Machinery and Propulsion |
|
|
Main engines |
12АSV 25/30 model 3 x diesel engines manufactured by "Zulzer” with a capacity of 3 х 2147 kW (3 х 2920) at 1000 rpm. |
|
Generator |
3 x diesel powered main generator sets. Generators with a voltage of 6000 V, 50 Hz at 1000 rpm, with a capacity of 3 х 2700 kW, manufactured by АЕG. |
|
Emergency generator |
One diesel generator equipped with either ТВD616 V12G3 type diesel engine with a capacity of 738 kW at 1500 rpm and generator with a voltage of 380 V, frequency of 50 Hz and capacity of 618 кVA (495 кW). |
|
Anchor Handling & Mooring Gear |
|
|
Anchors |
8 pieces of MUD type anchors manufactured by "Bloom and Voss", each weighing 18000 kg. |
|
Anchor chains |
3000m long, 71 mm diameter for 200 m depth, ultimate breaking load 225000 kg. |
|
Mooring gear |
6 pieces of D=26mm, 200m long mooring wires. Ultimate breaking load – 34800 kg. |
|
Mooring capstan |
With capacity of 18,5 kW, 8 tons of pull force at 12 meters per minute speed of the wire. |
|
Deck Crane |
|
|
carrying capacity |
2000/2500 tons. |
|
Safety Equipment |
|
|
Life rafts |
16 x 25 person |
|
Lifejackets |
405 |
|
Immersion Suits |
200 |
|
Rescue boat |
1 x 6 person |
|
Accommodation |
|
|
Cabins |
64 |
|
Crew, person |
50 |
|
Client personnel, person |
146 |
|
Hospital |
1 |
|
Navigation & Communication Equipment |
|
|
Radar – 1 x Kelvin Nucleus; Echo sounder – 1 x Furuno; Gyro compass – 1 x Standart 22; GPS – 1 x Furuno; MF/HF transceiver – 1 x Furuno; GMDSS – 1 x Inmarsat C; VHF – 2 x Furuno |
|
