Dimensions |
|
|
Length overall, m |
64,39 |
|
Length between perpendicular, m |
60,0 |
|
Breadth, m |
15,02 |
|
Hull height, m |
4,02 |
|
Overall height, m |
20,6 |
|
Displacement of the vessel unloaded, t |
1264 |
|
Displacement of vessel fully loaded, t |
1720 |
|
Draft, m |
2,4 |
|
Deadweight, t |
456 |
|
Net Tonnage, t |
419 |
|
Gross tonnage, t |
1384 |
|
Capacities |
|
|
Crew, person |
20 |
|
Speed, knots |
11,24 |
|
Fresh Water, t |
70 |
|
Ballast / drill water, m3 |
487 |
|
Fuel capacity, t |
169 |
|
Greasing oil capacity, t |
2,3 |
|
Cargo hold, t |
50 |
|
Deck cargo capacity, t |
250 |
|
Deck strength, ton/ m2 |
4-6 |
|
Clear deck area, m2 |
252 |
|
Clear deck area (max L x B) |
21x12 |
|
Endurance |
15 |
|
General Data |
|
|
IMO number |
8613774 |
|
Port of registry / Call sign |
Baku / 4JKO |
|
Purpose of the Ship |
Crane Vessel |
|
Flag |
Azerbaijan |
|
Year built / builder |
1989 / Shipyard named after Varsky, city of Shezin, Poland |
|
Class |
KM (*) L3 [1]R1 AUT2 Crane Vessel |
|
Machinery and Propulsion |
|
|
Main engines |
2 x diesel engines of medium-speed, non-reversible, equipped with 8АL20 / 24 type supercharge with a capacity of 2 × 558.8 kW, (2 × 760 BHP) at 750 rpm |
|
Diesel generators |
2 x 6АL 20/24-500-50 type diesel generators with a capacity of 2 х 420 kW, 380 V, 50 Hz at 750 rpm. |
|
Emergency generator |
One ZE400 type emergency diesel generator produced in Poland, with a capacity of54 52 kVA, 1500 rpm, GCPF 94С/1 generator. |
|
Anchor Equipment |
|
|
Capstan |
Electric |
|
Bow anchor winches |
2 x 1750kg |
|
Chain |
2 x 220m, D=36 |
|
Safety Equipment |
|
|
Life rafts |
2 x 20 person |
|
Fast rescue boat |
2 pcs |
|
Life buoy |
8 |
|
Life jacket |
20 |
|
Immersion suit |
20 |
|
Embarkation ladder |
2 |
|
Accommodation |
|
|
Max per LSA |
20 |
|
1 berth cabin |
9 |
|
2 berth cabins |
9 |
|
Clinic |
1 |
|
Crane Characteristics |
|
|
General information |
Full circle slewing, power driven deck crane is installed on the bow of the ship and the crane has 40t lifting capacity with auxiliary lift and 8t lifting capacity with capacity limiter. |
|
NAVIGATION EQUIPMENT |
|
|
MF/HF FS-1575T-1pcs, VHF FM-8500-1pcs, VHF FM-8900S-2pcs, EPIRB McMurdo E3a-1pcs, SART McMurdo RT9-2pcs, UAIS SI-30-1pcs, RLS Koden MDC-2910P-2pcs, VHF ICOM IC-M25EURO-1pcs, VHF ICOM IC-M23-1pcs, INM-C Felcom-18-1pcs, INM-C Felcom-18/SSAS-1pcs |
|
